ATEX Drum Elevator

Applications & Use Cases

• Transferring powders or granules from drums into process vessels or hoppers within hazardous environments.
• Loading ingredients into mixers or reactors in pharmaceutical or chemical manufacturing.
• Elevating waste materials from drums for disposal or further processing in ATEX zones.
• Feeding packaging lines with bulk materials from drums in industries handling flammable substances.

Typical Specifications

Typical drum capacity

Units of this type commonly handle standard 200-250 litre drums; smaller or larger drums may be accommodated depending on the specific design.

Lifting height

Typically designed for discharge heights ranging from 1.5m to 4m, suitable for feeding various processing equipment.

Power supply

Often electrically powered, requiring a 3-phase supply (e.g., 400V, 50Hz) with appropriate ATEX-rated components.

Construction material

Commonly constructed from stainless steel (e.g., 304 or 316L) for hygiene and corrosion resistance, particularly in food or pharmaceutical applications.

ATEX rating

This unit is specified as ATEX-compliant, indicating suitability for use in designated hazardous areas (e.g., Zone 1, Zone 21).

Footprint

For this class of equipment, the footprint typically ranges from 1.5m x 1.5m to 2.5m x 2.5m, depending on lifting height and drum handling mechanism.

Frequently Asked Questions

• What does 'ATEX' signify for this drum elevator?

  ATEX certification means the equipment is designed and constructed to safely operate in potentially explosive atmospheres, preventing ignition of flammable gases, vapours, mists, or dusts.

• What types of drums can this unit typically handle?

• Is installation complex for an ATEX drum elevator?

• What maintenance is typically required for this type of equipment?

• Can this unit be integrated into an existing production line?
