Bayer Diagnostics - Tissue-Tek 4715 Embedding Console with Cryo Console

Applications & Use Cases

• Preparing tissue samples for microscopic examination in pathology laboratories.
• Embedding biological specimens in paraffin wax for sectioning.
• Creating tissue blocks for immunohistochemistry and molecular pathology.
• Facilitating precise orientation of samples for diagnostic analysis.

Typical Specifications

Typical capacity

Often features a large paraffin reservoir, typically holding 3-5 litres, and multiple heated wells for cassettes and moulds.

Power supply

Commonly operates on standard laboratory power, typically 230V, 50Hz for UK installations, with a power consumption in the range of 500-1000W.

Temperature range (embedding module)

Paraffin bath and heated wells typically maintain temperatures between 55°C and 70°C.

Temperature range (cryo module)

The integrated cryo console typically provides a cooling surface temperature of -5°C to -15°C for rapid tissue block solidification.

Footprint

For this class of equipment, a combined embedding and cryo console typically requires a bench space of approximately 60-80 cm width and 50-70 cm depth.

Controls

Units commonly feature independent temperature controls for different modules (paraffin reservoir, heated wells, cryo plate) and often include programmable timers.

Frequently Asked Questions

• What is an embedding console used for?

  An embedding console is used in histology and pathology labs to embed processed tissue samples into paraffin wax blocks. This provides structural support for subsequent thin sectioning.

• Why is a cryo console included with an embedding console?

• What maintenance is typically required for this type of equipment?

• Can this unit be used with different types of tissue cassettes and moulds?

• What safety considerations are important when operating an embedding console?
