Belt Conveyor

Applications & Use Cases

• Moving products between processing stages in food manufacturing.
• Transporting packaged goods in warehousing and logistics operations.
• Handling bulk materials such as grains, powders, or aggregates.
• Integrating into automated production lines for continuous material flow.

Typical Specifications

Typical belt width

Commonly ranges from 300mm to 1200mm, depending on application.

Typical length

For this class of equipment, lengths can vary significantly, often from 2 metres to over 20 metres.

Typical capacity

Throughput typically depends on belt speed, width, and material density, often measured in tonnes per hour or items per minute.

Power supply

Most industrial belt conveyors commonly operate on 400V, 3-phase power, though smaller units may use single-phase.

Frame material

Frames are typically constructed from mild steel (painted or powder-coated) or stainless steel for hygienic applications.

Belt material

Belts are commonly made from PVC, PU, rubber, or modular plastic, selected based on product type and environment.

Speed control

Many units feature variable speed drives for adjustable throughput, commonly controlled via an inverter.

Frequently Asked Questions

• What should I consider regarding the 'used' condition of a conveyor belt frame?

  When purchasing a used frame, inspect for structural integrity, signs of corrosion, and wear on bearing points. The absence of a belt means you will need to source one to fit.

• Can I easily fit a new belt to a used frame?

• What are the typical maintenance requirements for a belt conveyor?

• Is this type of equipment suitable for food contact applications?

• What safety features should I look for on a used conveyor frame?
