What type of bins can this lift accommodate?

This specific unit is designed for Dolaf bins. However, platform lifts can often be adapted or specified to handle various standard industrial or food-grade bins and containers.

Is customisation for specific lift heights or loads possible?

Yes, manufacturers often offer customisation options for lift height, safe working load, and platform dimensions to suit specific operational requirements.

What are the typical safety features on such equipment?

Common safety features include emergency stop buttons, safety guarding, overload protection, and interlocks to prevent operation under unsafe conditions.

Does this equipment require a pit for installation?

Many modern platform lifts, including this design, are engineered for floor mounting, negating the need for costly and time-consuming pit construction.

What maintenance is typically required for a Dolaf bin platform lift?

Routine maintenance typically involves checking chains for wear, lubricating moving parts, inspecting electrical connections, and verifying safety interlocks. A planned preventative maintenance schedule is recommended.

Dolaf Bin Platform Lift - Lifting & Tipping, photo 1

Dolaf Bin Platform Lift - Lifting & Tipping, photo 2

Dolaf Bin Platform Lift - Lifting & Tipping, photo 3

Dolaf Bin Platform Lift - Lifting & Tipping, photo 4

Dolaf Bin Platform Lift - Lifting & Tipping, photo 5

Dolaf Bin Platform Lift - Lifting & Tipping, photo 6

Dolaf Bin Platform Lift - Lifting & Tipping

Available

Verified seller

Base Handling Ltd - Dolaf Bin Platform Lift

Name: Dolaf Bin Platform Lift
Brand: Base Handling Ltd
SKU: PLM/2P/1000/4000/B/G
Availability: InStock

Price: Contact seller for price

PLM/2P/1000/4000/B/G Dolaf Bin Platform Lift.

This Dolaf Bin Platform Lift had a Safe Working Load of 1000 Kgs to raise Dolaf Bins to a transfer conveyor at a lift height of 4000mm.

The lifting platform was big enough to allow a Dolaf Bin Transfer Conveyor to be mounted on the lift carriage.

The Dolaf Bin Platform Lift was manufactured from Grade 304 stainless steel and is a welded construction throughout.

The machine is designed to be bolted to the floor without the need for a pit.

The lifting is accomplished via chains driven by a motor gearbox mounted at the top of the one colum n with a crossover shaft to the other column.

Dolaf Bin Platform Lift Electrical Control.

This Dolaf Bin Platform Lift was fitted with an IP65 Stainless Steel Terminal Box which was mounted on the safety guard at the lower level for the control to be completed by others.

The following components were be wired back to the terminal box:-

1 off

Blaenau Gwent County Borough, United Kingdom

5,743 km away

Description

1000 Kgs Dolaf Bin Platform Lift

Model No.

PLM/2P/1000/4000/B/G

Capacity

1000 Kgs

Overall Height

6203mm

Machine Handing

Right Hand Or Left Hand

Maximum Headroom

7800mm

Container Description

1200 x 1000 x 880mm Dolaf Container

Base Arrangement

Bolted To The Floor

Electrical Rating

IP65

Limit Switches

Telemecanique

Motor Detail

2.2kW, 415V, 3 PHASE, 50 CYCLE & BRAKE

Gearbox Detail

SEW Eurodrive

Tensile Strength

6000 Kgs, 3000 Kgs

Lift Speed

6.4 Meters/Minute

Tension Chain

¾” Simplex

Platform Size

1400 x 1300mm Wide

Lift Height

4000mm

Lift Chain

1" Simplex

Stock Number

PLM/2P/1000/4000/B/G

Machinery Masters View

Typical context for this category of equipment. Always confirm specifics with the seller.

Elevating Dolaf bins for transfer to processing lines.
Loading ingredients into mixers or other processing machinery.
Integrating into automated food production systems for material handling.
Transferring bulk ingredients between different levels in a facility.

Typical Safe Working Load (SWL): Units of this type commonly handle loads from 500 kg to 2000 kg.
Maximum Lift Height: Commonly, these lifts achieve heights between 2000 mm and 5000 mm.
Construction Material: For food processing applications, Grade 304 stainless steel is standard, with Grade 316 an option for more corrosive environments.
Power Supply: Typically requires a 3-phase electrical supply, commonly 400V, 50Hz.
Mounting: Many models are designed for floor bolting, eliminating the need for a pit.
Drive System: Chain-driven systems powered by a motor gearbox are commonly employed for robust lifting.
Electrical Enclosure Rating: IP65 rated enclosures are typical for washdown environments in food processing.

This specific unit is designed for Dolaf bins. However, platform lifts can often be adapted or specified to handle various standard industrial or food-grade bins and containers.

Lifting and tipping equipment for food handling is valued for durability and reliability in demanding environments. Buyers typically prioritize robust construction, stainless steel components where applicable, and compliance with food safety standards. When purchasing used models, inspectors should assess mechanical wear, hydraulic system condition, and operational smoothness. Common strengths include longevity when properly maintained, efficient load handling, and adaptability to various food processing workflows. Equipment reputation generally remains strong provided previous maintenance records are documented and critical seals show minimal degradation.
