Gantry

Applications & Use Cases

• Used in workshops and factories for localised lifting tasks.
• Commonly found in assembly lines for positioning components.
• Utilised in warehouses for loading and unloading smaller items.
• Applied in maintenance departments for engine removal or machinery repair.
• Suitable for material handling in fabrication shops.

Typical Specifications

Typical lifting capacity

For this class of equipment, capacities typically range from 500kg to 5,000kg, depending on design and construction.

Construction material

Gantries are commonly constructed from robust steel sections (e.g., mild steel, structural steel) for strength and durability.

Power supply

Manual gantries require no external power. Powered versions typically operate on 400V 3-phase electricity for hoist and trolley movement.

Mobility

Many smaller gantries are mobile, fitted with heavy-duty castors. Larger units may be fixed or semi-permanent.

Span and height

The span (width) and height under the beam vary significantly. The listed unit's internal dimension suggests a specific application footprint.

Hoist compatibility

Gantries are designed to accommodate various hoist types, including manual chain hoists, electric chain hoists, or wire rope hoists.

Frequently Asked Questions

• What is the primary function of a gantry?

  A gantry provides an overhead structure for mounting a hoist, allowing for the lifting and horizontal movement of loads within a defined area.

• Are gantry cranes easy to relocate?

• What maintenance is typically required for a gantry?

• Can I use any hoist with this gantry?

• What safety considerations are important when operating a gantry?
