Gericke PTA50 Pneumatic Conveying System

Applications & Use Cases

• Transferring powdered ingredients in bakeries and food production facilities.
• Moving chemical compounds in pharmaceutical manufacturing.
• Conveying granular materials in plastics processing.
• Dosing fine powders in nutraceutical and supplement production.

Typical Specifications

Typical conveying capacity

For this class of equipment, throughput can range from hundreds of kilograms to several tonnes per hour, depending on material density and conveying distance.

Power supply

Pneumatic conveying systems commonly require a 3-phase electrical supply, typically 400V, 50Hz, for compressors and control systems.

Working pressure

Units of this type commonly operate with working pressures between 2 and 6 bar.

Typical volume

Receiver volumes for mobile pneumatic conveying systems often range from 50 to 200 litres.

Material compatibility

Stainless steel construction, as seen on this unit, is standard for food, chemical, and pharmaceutical applications due to hygiene and corrosion resistance requirements.

Footprint

Mobile units are designed for flexibility, with a compact footprint typically allowing easy relocation within a facility.

Control system

Modern systems commonly feature PLC-based controls for automated operation, including dosing and transfer cycles.

Frequently Asked Questions

• What types of materials can this system convey?

  This type of system is typically suitable for conveying a wide range of dry, free-flowing powders and granular materials, including flours, sugars, starches, chemicals, and pharmaceutical intermediates.

• Is this system suitable for hazardous materials?

• What maintenance is typically required for a pneumatic conveying system?

• Can this system be integrated into an existing production line?

• What are the advantages of a mobile pneumatic conveying system?
