QuattroFlow QF150 Diaphragm Pump

Name: QuattroFlow QF150 Diaphragm Pump
Brand: QuattroFlow
SKU: 413006
Price: 2250 GBP
Availability: InStock

Price: £ 2,250

This listing is for a QuattroFlow QF150 Diaphragm Pump.

The unit is in full working condition and is ready for immediate release.

The Quattroflow 150S is a 4-piston Diaphragm pump, which is mainly used to pump water-like fluids that are typically handled in research-, pilot plant- or production facilities of the pharmaceutical, biotech,food or cosmetic research centres or plants.

Examples:

Solutions containing proteins (albumin, IgG, Clotting factors, monoclonal antibodies, enzymes, vaccines.).
Solutions of polymers or suspensions (silicon, latex, chromatography media).
Cell suspensions (bacteria, yeast, algae, fungi, mammalian cells).
colloidal solutions.
Suspensions of viruses or phage.
Dairy products.
Gelatine.
Supplements and ingredients for cosmetic and food.

Flow rate max.:

Eccentric shaft 3° l/h (lpm) 100 (1.67) 100 (1.67).

Eccentric shaft 5° l/h (lpm) 180 (3) 180 (3).

Flow rate min.:

Eccentric shaft 3° l/h (lpm) 1 (0.017) 1 (0.017).

Eccentric shaft 5° l/h (lpm) 1 (0.017) 1 (0.017).

Pressure:

Temperature of fluid < 40°C bar (psi) 6 (87) 6 (87).

Temperature of fluid > 40°C bar (psi) 4 (58) 4 (58).

Temperature max.:

Fluid °C (°F) 80 (176) 80 (176).

CIP °C (°F) 90 (194) 90 (194).

SIP °C (°F) 130 (260) 130 (260).

Autoclave °C (°F) 130 (260) 130 (260).

Suction lift dry at: 3000 rpm 3000 rpm.

Eccentric shaft 3° m (ft) 1-1,5 (3.2-4.9) 1-1,5 (3.2-4.9).

Eccentric shaft 5° m (ft) 2-3 (6.6-9.8) 2-3 (6.6-9.8).

Volume specifications:

Approximated volume per revolution at free output ml 0,72 (3°).

1,2 (5°).

0,72 (3°).

1,2 (5°).

Filling volume without connectors ml 15 15.

Residual volume (after idle with highspeed motor) ml 1-3 1-3.

Product wetted surface (approx.) cm² (inch²) 112 (17) 112 (17).

Speed range pump rpm 10-3000 10-3000.

Connection specification inlet (standard).

Connector " 1/4" TC 1/4" TC.

Flange diameter mm (inch) 25 25.

Internal diameter mm (inch) 4,7 4,7.

Connection specification outlet (standard).

Connector " 1/4" TC 1/4" TC.

Flange diameter mm 25 25.

Internal diameter mm (inch) 4,7 (0.19) 4,7 (0.19).

Position of connectors Inline Inline.

Number of flow directions 4 4.

Diameter drive shaft mm 7 7.

Product wetted materials (standard):

Pump housing SS316L SS316L.

Valve plate SS316L SS316L.

Diaphragms Santoprene Santoprene.

Valves EPDM EPDM.

O-rings EPDM EPDM.

Non-product wetted materials (standard):

Pump housing SS316L SS316L.

Bearing housing SS316L SS316L.

Base plate SS316 SS316.

Hood SS316 SS316.

Dimensions pump with motor and housing:

Length mm (inch) 257 (10,2) 277 (10-91).

Width mm (inch) 164 (6,5) 200 (7,87).

Height mm (inch) 185 (7,2) 195 (7,67).

Weight pump with motor and housing kg (lb) 9,8 (22) 11,2 (25).

IP protection class pump IP 54 54.

Operating temperature range °C (°F) 0…40 (32…104) 10…30 (50…86).

Cambridgeshire, United Kingdom

5,773 km away

Model Number

QF15ACUEGN-UK

Stock Number

413006

Machinery Masters View

Typical context for this category of equipment. Always confirm specifics with the seller.

Transfer of shear-sensitive biological solutions such as proteins, vaccines, and cell suspensions in pharmaceutical and biotech settings.
Handling of colloidal solutions and suspensions of polymers or chromatography media.
Pumping of various dairy products, gelatine, and other food ingredients.
Transfer of cosmetic ingredients and supplements requiring gentle handling.
Use in research, pilot plant, and production facilities where precise and gentle fluid transfer is critical.

Typical Flow Rate Range: For this class of equipment, flow rates commonly range from 1 l/h up to 180 l/h, depending on the eccentric shaft setting.
Maximum Discharge Pressure: Units of this type typically operate up to 4 bar (58 psi) at standard fluid temperatures.
Fluid Temperature Range: Commonly handles fluids up to 80°C (176°F).
CIP/SIP Capability: Designed for Clean-in-Place (CIP) up to 90°C (194°F) and Sterilise-in-Place (SIP) up to 130°C (260°F).
Autoclave Compatibility: Components are typically suitable for autoclaving up to 130°C (260°F).
Suction Lift (Dry): Commonly achieves a dry suction lift of 1 to 3 metres, depending on the eccentric shaft setting and RPM.
Diaphragm Type: Features a 4-piston diaphragm design, known for gentle product handling.

This pump is primarily designed for water-like fluids, especially those requiring gentle handling such as protein solutions, cell suspensions, and other shear-sensitive biological or food products.

Diaphragm pumps are generally valued for their reliability and versatility across laboratory and pharmaceutical applications. Buyers typically prioritise condition of the diaphragm itself, seals and valve integrity when purchasing used units. Industry sentiment favours their gentle handling of sensitive fluids, low maintenance requirements and ability to manage viscous or abrasive media. Common strengths include self-priming capability, compact design and suitability for both suction and discharge applications. Durability remains a key selling point.
