What is a 'jacketed' tank?

A jacketed tank has an outer shell that creates a space (the jacket) around the inner vessel. This space can be filled with a heating or cooling fluid to precisely control the temperature of the contents within the inner vessel or single-use bag.

What does 'single-use mixing systems compatible' mean?

It means the stainless steel tank is designed to hold and support a disposable plastic bag (the single-use component) where the actual mixing and storage occur. This eliminates the need for cleaning and sterilisation of the primary product contact surface.

Is the mixer included with this listing?

The listing states 'Integrated Pro Mixer Compatibility' and 'Railed port enables quick coupling of the mobile Pro Mixer drive unit'. This implies the tank is ready for a mixer, but the mixer drive unit itself may be a separate item. Buyers should confirm with the seller.

What are the benefits of a cubical design?

Cubical designs typically offer better space utilisation compared to cylindrical tanks, allowing for more efficient storage and processing within a facility footprint. They can also be easier to integrate into automated systems.

What maintenance is required for this type of equipment?

Maintenance typically involves routine inspection of the stainless steel exterior, jacket connections, and any associated control systems. As the primary product contact is a single-use bag, internal cleaning of the tank itself is minimal, focusing on external hygiene.

Can this tank be used for applications other than biopharmaceutical?

While designed for biopharmaceutical use, the principles of temperature-controlled mixing and storage could be applicable to other sensitive liquid handling processes in industries such as food & beverage, fine chemicals, or cosmetics, provided the single-use bag material is compatible with the product.

Home
/
Labs, Biotech & Pharma
/
Bioprocessing & Pharmaceutical Manufacturing
/
Process Vessels & Storage Tanks
/
Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank

Used Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank - Process Vessels & Storage Tanks, photo 1

Used Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank - Process Vessels & Storage Tanks, photo 2

Used Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank - Process Vessels & Storage Tanks, photo 3

Used Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank - Process Vessels & Storage Tanks, photo 4

Used Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank - Process Vessels & Storage Tanks, photo 5

Used Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank - Process Vessels & Storage Tanks

used Equipment

Available

Verified seller

Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank

Name: Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank
Brand: Sartorius Stedim
SKU: 413086
Price: 5950 GBP
Availability: InStock

Price: £ 5,950

This listing is for a Sartorius Stedim Palletank Cubical Jacketed-Mix 200L Storage Tank.

The unit is in full working condition and is ready for immediate release.

Unit is supplied with x2 Sartorius 200L STD Plastic Palletank and dolly.

The Sartorius Stedim Palletank Cubical Jacketed-Mix 200L is a high-performance storage and mixing solution designed for biopharmaceutical applications.

Engineered for compatibility with Sartorius single-use mixing systems, this temperature-controlled stainless steel tank provides efficient liquid handling, precise temperature control, and optimized mixing performance.

Key Features:

Jacketed Temperature Control – Ensures precise heating or cooling for sensitive bioprocess applications.
200L Capacity – Ideal for medium-scale liquid storage and mixing in GMP environments.
Ergonomic Design – Front doors allow for easy bag installation and port gates facilitate tubing and sensor integration.
Integrated Pro Mixer Compatibility – Railed port enables quick coupling of the mobile Pro Mixer drive unit in under a minute.
Optimized Draining System – Sloped bottom board ensures high product recovery without manual bag manipulation.
Weighing Function Option – Allows for precise volume control, preventing aggregate formation and ensuring product quality.
Visual Inspection Windows – Side windows enable real-time process monitoring during mixing.
Surface Finish Options – Available in Bead Blast or ASME #4 brushed finish for enhanced corrosion resistance and cleanability.

Specifications:

Model: Palletank Cubical Jacketed-Mix 200L

Capacity: 200 Liters

Material: Stainless Steel

Jacket Type: Temperature-Controlled Jacket

Mixing Type: Integrated Pro Mixer Compatibility

Drainage System Sloped Bottom for High Recovery

Application Storage & Mixing for Bioprocessing

Compliance GMP, Biopharma Standards

Benefits:

Precise Temperature Control – Maintains optimal conditions for biologics and cell culture media.
Efficient Mixing – Designed for homogeneous blending of process liquids, buffers, and media.
Enhanced Process Control – Weighing and volume control prevent aggregate formation.
Easy Integration – Compatible with Sartorius Flexsafe® Bags & Biostat® Systems.
Ergonomic & User-Friendly – Front door access and port gates for seamless tubing and sensor installation.
Durable & Hygienic – Stainless steel GMP-compliant construction with highly cleanable surfaces.

Applications:

Biopharmaceutical Manufacturing
Cell Culture & Media Preparation
Buffer & Reagent Storage
Vaccine & Protein Processing

Cambridgeshire, United Kingdom

5,773 km away

Model Number

Palletank Cubical Jacketed-Mix 200L

Stock Number

413086

Machinery Masters View

Typical context for this category of equipment. Always confirm specifics with the seller.

Biopharmaceutical processing for media preparation, buffer storage, and product intermediate holding.
Cell culture and fermentation processes requiring controlled temperature and mixing.
Preparation and storage of sensitive biological solutions in GMP environments.
Vaccine production and other sterile fluid handling operations.
Pilot-scale and small-to-medium batch production in biotech and pharmaceutical industries.

Typical capacity: This specific unit is 200L; units in this class commonly range from 50L to 1000L.
Temperature control: Jacketed design typically allows for precise heating and cooling, often via a recirculating fluid system.
Mixing capability: Designed for compatibility with single-use mixing systems, typically employing magnetic or overhead drive units.
Construction material: For this class of equipment, the outer tank is typically 304 or 316L stainless steel, compatible with single-use bags.
Footprint: Cubical design optimises space; exact dimensions should be confirmed with the seller, but typically designed for efficient facility integration.
Power supply: Mixing drive units typically require a standard industrial single-phase or three-phase supply, commonly 230V or 400V, 50Hz for UK operations. Jacketing may require connection to a facility's utility supply.
Drainage: Units of this type commonly feature a sloped bottom for optimised product recovery from the single-use bag.
Compatibility: Specifically designed for use with Sartorius single-use Palletank bags and Pro Mixer drive units.

A jacketed tank has an outer shell that creates a space (the jacket) around the inner vessel. This space can be filled with a heating or cooling fluid to precisely control the temperature of the contents within the inner vessel or single-use bag.

Process vessels and storage tanks for bioprocessing and pharmaceutical manufacturing are valued for robust construction and compliance with GMP standards. Buyers typically seek equipment with verified validation documentation, material certifications, and service history. Common strengths include reliable performance in temperature-controlled environments and compatibility with existing systems. When purchasing used equipment, industry practice emphasises inspecting pressure ratings, gasket conditions, and calibration records. Quality units from established manufacturers generally command confidence in secondary markets.

General overview for this equipment type

Machinery Masters Intelligence. General guidance for this category of equipment only, not a substitute for the seller's exact specifications. Always confirm details with the seller.
