Sysmex - Sysmex PU-17 Pneumatic Unit

Applications & Use Cases

• Providing vacuum for laboratory analysers, particularly in haematology.
• Supporting fluid aspiration and transfer in biotech and pharmaceutical processes.
• Enabling precise liquid handling in automated laboratory systems.
• Facilitating sample preparation and analysis in clinical diagnostics.
• Operating pneumatic control systems in various research and industrial settings.

Typical Specifications

Typical vacuum pressure

Units of this type commonly generate vacuum levels suitable for analytical instrumentation, often in the range of -50 kPa to -80 kPa.

Flow rate

For this class of equipment, flow rates are typically designed to meet the demands of connected analysers, often ranging from 5 to 20 litres per minute.

Power supply

Pneumatic units commonly operate on standard laboratory power supplies, typically 230V, 50Hz in the UK.

Footprint

These units are generally compact, designed for benchtop use or integration within analyser systems, with typical dimensions around 20-30 cm per side.

Noise level

Modern pneumatic units are often designed for low noise operation, typically below 60 dB, to suit laboratory environments.

Connectivity

Units commonly feature standard pneumatic fittings for connection to analysers and often include electrical interfaces for control and status monitoring.

Frequently Asked Questions

• What is the primary function of a pneumatic unit in a laboratory setting?

  A pneumatic unit primarily serves as a reliable vacuum or pressure source, essential for the accurate operation of various laboratory instruments, particularly for fluid aspiration and transfer.

• Are these units compatible with all laboratory analysers?

• What maintenance is typically required for a pneumatic unit?

• Can a used pneumatic unit be integrated into an existing system?

• What are the safety considerations when operating a pneumatic unit?
