What types of products are suitable for a rotary table?

Rotary tables are generally suitable for stable, non-fragile products that can accumulate without damage, such as bottles, jars, cartons, and small packaged goods.

How does a rotary table integrate into an existing line?

These units are typically standalone and can be positioned at the end of a conveyor or processing line to accumulate products. They often feature adjustable height to match existing line levels.

Are there different material options for rotary tables?

Yes, common options include plastic laminated tops for general use, solid plastic for durability, and stainless steel with plastic tops for hygienic or food-grade environments.

Can the speed of the rotary table be adjusted?

Many rotary tables offer fixed speed options, and some higher-spec units or those with specific customisation can be supplied with adjustable speed control to suit different production rates.

What maintenance is typically required for a used rotary table?

Maintenance is generally low, focusing on regular cleaning, checking motor and bearing lubrication, and inspecting the tabletop and drive mechanism for wear. Buyers should confirm specific maintenance history with the seller.

used Equipment

Available

Verified seller

/images/stories/virtuemart/product/DG00083.jpg - Rotary Table

Name: Rotary Table
Brand: /images/stories/virtuemart/product/DG00083.jpg
SKU: DG00057
Availability: InStock

Price: Contact seller for price

Rotary tables for packaging stations A simple and cost-efficient solution to accumulation. SOCO SYSTEM's rotary table is suitable for accumulation of e.g. retail products. The operator is free to perform other jobs, while, at the same time, interruption of the arrival of products is avoided. Rotating on the table, the articles are constantly within easy reach. A rational work station offering correct working conditions. A fan directs the products, and the table is prepared for side guides. The legs are height adjustable. Diameter: ? 1200 mm. Height: Min. 715 mm. Speed: Standard 6.00 rotations per minute. Upon request 3.77, 2.81 and 2.20 rotations per minute are available. Adjustable speed control can also be supplied. The rotary table is available in three different versions: Model A: Rotary table with plastic laminated tabletop. Model B: Rotary table with tabletop made of solid plastic. Model C: Rotary table in 18/8 stainless steel with tabletop made of solid plastic. Braked castors: SOCO SYSTEM castors are of sturdy construction with efficient brakes that lock in the direction of travel and rotation. Standard on SOCO SYSTEM rotary tables.

Galway, Ireland

5,966 km away

Stock Number

DG00057

Machinery Masters View

Typical context for this category of equipment. Always confirm specifics with the seller.

Applications & Use Cases

Accumulation of products at the end of a packaging line.
Buffering items for manual packing or inspection stations.
Providing a continuous supply of components for assembly operations.
Sorting and singulation of small to medium-sized retail products.
Facilitating ergonomic access to products for operators.

Typical Specifications

Typical diameter: Commonly ranges from 800mm to 1500mm for this class of equipment.
Typical height adjustment: Units often feature adjustable legs, typically allowing for a working height range suitable for various operators.
Power supply: Typically single-phase industrial electricity, often 230V, 50Hz in the UK.
Rotational speed: Commonly offers a range of fixed speeds or variable speed control, typically from 2 to 10 rotations per minute.
Construction materials: Often available in painted mild steel, plastic laminated tops, solid plastic, or stainless steel for food-grade applications.
Footprint: The footprint is primarily defined by the table's diameter, plus any motor housing or control panel.

Frequently Asked Questions

Rotary tables are generally suitable for stable, non-fragile products that can accumulate without damage, such as bottles, jars, cartons, and small packaged goods.

Machinery Masters Intelligence. General guidance for this category of equipment only, not a substitute for the seller's exact specifications. Always confirm details with the seller.
